Description
[et_pb_accordion open_toggle_background_color=”#FFFFFF” closed_toggle_background_color=”#FFFFFF” icon_color=”#E02B20″ _builder_version=”5.0.0-public-alpha.18.2″ custom_margin=”-24px|||||” db_closeable=”on” global_colors_info=”{}” layout_display=”block”][et_pb_accordion_item title=”PHYSICAL CHARACTERISTICS” open=”on” open_toggle_background_color=”#FFFFFF” closed_toggle_background_color=”#FFFFFF” icon_color=”#E02B20″ open_icon_color=”#E02B20″ _builder_version=”4.19.4″ global_colors_info=”{}”]SIZE
292mm (w) x 231mm (h) x 50mm (d)
11.5 inch (w) x 9.1 inch (h) x 2 inch (d)
WEIGHT
2.85 kg / 6.45 LB
BLUETOOTH
Bluetooth v5.0 + BLE
WLAN
Dualband WLAN 802.11 ac, 802.11 a/b/g/n
RFID/NFC
NFC for login
WWAN
WWAN & GPS (Optional)
ANTENNAS
WLAN dual diversity antennas (IFA)
3 external (SMA) for WWAN & GPS or WLAN
and Bluetooth antennas
AUDIO
Encapsulated audio exciters
HD audio
INDICATORS
Power status
Wi-Fi connection status
BUTTONS
6x Capacitive touch buttons
Power
LED dimming +/-
or Volume +/-
PORTS
1x USB C 3.1 (OTG & DP)
3x USB A 2.0
1x Ethernet 10/100/1000
1x RS232 with 5V (power feed at pin 1 or 9)
POWER SUPPLY
INPUT
9-72 VDC isolated
UPS
Internal battery for graceful shut down at unexpected power outages
900 mAh STD or 1800 mAh Performance (optional)
POWER CONSUMPTION
~15W* (standby/off mode = 0.5 W)
PROCESSOR
Qualcomm® SnapDragon™ 660
1.90GHZ & 2.20GHz
MEMORY
4GB LPDDR4
DISPLAY
12.1” XGA LED 1000 NIT
12.1” XGA LED 500 NIT
Capacitive touch screen with JLT PowerTouch™ technology and hardened glass
Light sensors for adjustable auto-dimming
INTERNAL STORAGE
64Gb – eMMC 5.1 MLC
EXTERNAL STORAGE
SD Card up to 2 TB
OPERATING SYSTEM
Android 10 with GMS
SECURITY
TPM
OPERATING TEMPERATURES
-30° C to 55° C / -22° F to 131° F
STORAGE TEMPERATURES
-35° C to 75° C / -31° F to 167° F
HUMIDITY
10–95% RH
DUST AND WATER
IP65 – IEC 60529:2001
VIBRATION
5–500 Hz/0,04 m/s2 XYZ – IEC 60068-2-64 Fh
SHOCK
30g for 11ms XYZ – IEC 60068-2-27
MIL-SPEC
810G in applicable areas
